Dump Chute Control Modules

Request Quote ➟

Overview

3050957 , 3050958 , 3051090

Innovative Controls Dump Systems may contain between one and three DC Motor Controllers – either Single or Dual. Each DC Motor Controller is broken down into 4 functions:

(1. Open Valve / 2. Close Valve / 3. Chute Out / 4. Chute In)

Features

• Low side active limit switch inputs (high side active inputs also available)

• 2 spare inputs

• 1H-bridge @ 25A continuous, 45A peak solid state output

• CAN bus interface with J1939 protocol

• Status LEDs providing state of the module and the motors

Product Feedback >>>

PDFs:

Multiplex Dump and Chute Spec Sheet

(3050957) - Single DC Motor Drive Module

(3050958) - Dual DC Motor Drive Module

(3051090) - Dual Single Button DC Motor Drive Module

---
